Thermal Monocular For Hunting S25X II High Resolution Camera 640x480
Parameter:
| Item | S253 | S253H | S256 |
| | Detector type | Uncooled FPA |
| Resolution | 384×288 | 384x288 | 640×512 |
| Image | FOV | 14°x 10.5° | 10.7°x 8° | 17.7º ×14.3º |
| Focal length | 25mm manual focus | 35mm manual focus | 35mm manual focus |
| Focus range | 1m~∞ | 1m~∞ | 1m~∞ |
| NETD | <40mk@30℃ |
| Frame rate | 50HZ |
| Focus | Manual focus lens |
| Digital zoom | 1x~4x |
| Picture-in-Picture | Yes |
| Distance estimate | Yes |
| Spectrum range | 8-14μm |
| Image transmission | WiFi image transmission, support real-time browsing, photograph, video recording functions etc via mobile APP. |
| Cross cursor | Yes |
| Hot spot tracking | Yes |
| Laser indication, LED light | Yes |
| Image display | Display | 1280*960 (Eyepiece adjustable) |
| Image polarity | Black-hot, White-hot, Red-hot, Iron, Forest mode |
| Diopter adjustment | Adjust by rotary knob |
| Power supply | Battery type | Li-Ion battery, Rechargeable |
| Operation time | 5 hours continuous |
| Charging | USB charging and power bank support |
| External power | DC5V/2A (Micro USB) |
| Environment | Working temp. | -20℃- +50℃ |
| Storage temp. | -40℃- +60℃ |
| Protection class | IP66 |
| Drop resistance | 1 M |
| Physical characteristics | Weight | <0.5kg |
| Dimension | 190*70*70mm |
| Interface | Power interface | Yes |
| Video output | PAL |
| USB | External charging |
| Detection distance | Human 1.7*0.5 | 800m | 1100m | 1100m |
| Vehicle 2.3*2.3 | 1100m | 1500m | 1500m |
| Recognition distance | Human 1.7*0.5 | 400m | 550m | 550m |
| Vehicle 2.3*2.3 | 550m | 750m | 750m |
Features:
· Uncooled Thermal Monocular
· High sensitivity (384*288,17μm)
· Hand-held thermal imaging monocular.
· Small size, one-handed operation (moving observation), easy to carry.
· Video output
· New design for exterior, button and eyepiece, more comfortable and convenient to operate
· HD display screen with resolution 1280*960 for higher display range and image magnification.
· Live transmission through WIFI, APP real-time photographing, recording, motion alarm, thermal camera control and other operations on smartphone
· Various lens for optional to meet different needs
· Built-in distance estimation function.
· Built-in reticle and picture-in-picture function, more easy to observe and aim.
Observation Distance for reference:
Detection distance : 800m for a human who are in 1.8 x 0.5m (15mm lens)
1100m for a car which size is 2.3 x2.3m ( 15mm lens )
Recognition distance: 400m for a human who are in 1.8 x 0.5m ( 15mm lens )
550m for a car which size is 2.3 x 2.3m ( 15mm lens )
